YFR single tube short wave IR lamps are quartz halogen infrared emitters designed for fast radiant heating in industrial drying, curing, forming, preheating, softening, bonding, and replacement heating applications.
The single tube structure is suitable for equipment that requires compact installation, quick heat response, and focused radiant energy. These infrared lamps can be used as original equipment heating elements or as replacement IR lamps for existing machines.
YFR can manufacture single tube infrared lamps according to your required length, voltage, wattage, tube diameter, filament structure, reflector coating, end cap, lead wire, terminal type, and installation method.
| Feature | Description |
|---|---|
| Product Type | Single tube short wave IR lamp |
| Lamp Type | Quartz halogen infrared lamp |
| Heating Type | Short wave infrared radiant heating |
| Tube Material | Quartz glass tube |
| Structure | Single straight tube |
| Heating Response | Fast response for rapid heating processes |
| Custom Options | Length, voltage, power, tube diameter, coating, cap, wire, terminal |
| Replacement Use | Suitable for many existing industrial heating systems |
| Application | Drying, curing, forming, preheating, softening, bonding, heating |
Single tube short wave infrared lamps are widely used when a heating system needs fast start-up, compact lamp layout, and controlled radiant heat. The quartz tube structure allows the lamp to operate as a high-intensity radiant heating element, while the single tube shape makes it easy to install into many types of dryers, ovens, modules, and heating frames.
Compared with larger heating modules, single tube infrared lamps are easier to replace, customize, and integrate into existing equipment. This makes them suitable for machine builders, maintenance suppliers, and industrial users who need replacement lamps or customized IR heating components.
| Advantage | Practical Benefit |
|---|---|
| Fast radiant heat | Suitable for quick drying, curing, and preheating processes |
| Compact single tube design | Easy to install in narrow or limited heating spaces |
| Quartz halogen structure | Supports high-intensity infrared heating |
| Custom voltage and power | Can match different machines and regional power systems |
| Optional reflector coating | Helps direct heat toward the target material |
| Multiple end designs | Ceramic caps, metal ends, lead wires, terminals, or custom structures |
| Replacement support | Can be produced according to original lamp samples or drawings |
| OEM manufacturing | Suitable for equipment manufacturers and industrial heating projects |
| Industry | Typical Use |
|---|---|
| Printing | Ink drying, coating drying, varnish drying, adhesive activation |
| Packaging | PET bottle blowing, film heating, laminating, shrink packaging, sealing |
| Food Processing | Food drying, surface heating, packaging material forming |
| Glass Processing | Coating drying, preheating, annealing support, edge heating |
| Automotive | Paint drying, adhesive bonding, interior part heating, wire harness heating |
| Furniture | Waterborne and solvent-based coating drying |
| Rubber and Plastics | Surface heating, softening, thermoforming, molding, activation |
| Photovoltaic | Wafer soldering, sintering support, substrate drying, preheating |
| Textile | Fabric drying, coating drying, adhesive activation, pressing |
YFR single tube IR lamps can be produced with different tube surface options according to heating direction and equipment structure.
| Option | Typical Purpose |
|---|---|
| Clear quartz tube | Direct all-around radiant heating |
| Gold reflector coating | Directional heating toward the working side |
| White ceramic reflector coating | Reduces rear-side radiation and supports focused heating |
| Half-coated reflector | Suitable for one-sided heating modules |
| Custom coating | Produced according to the required heating direction and visual effect |
If your equipment already has an external reflector, a clear quartz lamp may be suitable. If the lamp needs to direct more heat toward one side, gold or ceramic reflector coating can be selected.
YFR can customize single tube infrared lamps for both new equipment and replacement applications.
| Custom Item | Available Options |
|---|---|
| Lamp Length | Customized according to machine structure |
| Heating Length | Designed according to effective heating area |
| Voltage | 24V, 110V, 120V, 220V, 230V, 240V, 380V, 400V, 480V, or customized |
| Power | Customized according to heating requirement |
| Tube Diameter | Customized according to lamp holder and power density |
| Tube Shape | Straight single tube or special shape by request |
| Reflector Coating | Clear, gold, white ceramic, half-coated, or customized |
| End Cap | Ceramic cap, metal cap, or special end structure |
| Lead Wire | High-temperature cable with customized length |
| Terminal | Bare wire, ring terminal, spade terminal, plug, pin, or custom connector |
| Packaging | Standard export packaging, neutral packaging, or OEM packaging |
YFR can produce single tube short wave IR lamps as replacement parts for existing industrial equipment. To check compatibility, please provide the original lamp information before ordering.
| Required Information | Example |
|---|---|
| Total lamp length | Overall length including end parts |
| Heating length | Effective heated section |
| Voltage and power | 230V 1000W, 400V 3000W, etc. |
| Tube diameter | Measured quartz tube diameter |
| End cap style | Ceramic cap, metal cap, no cap, or special connector |
| Lead wire length | Standard or customized |
| Terminal type | Ring terminal, spade terminal, pin, plug, or bare wire |
| Coating | Clear, gold reflector, ceramic reflector |
| Application | Printing dryer, packaging machine, paint oven, forming equipment |
| Photos or drawings | Complete lamp photo plus both end details |
If the original lamp marking is unclear, photos of the complete lamp, both ends, holder, and wiring position can help confirm the replacement design.
Single tube IR lamps can be installed individually or arranged in lamp banks for larger heating areas. A complete infrared heating system may include lamps, reflectors, ceramic holders, mounting clips, power controllers, temperature sensors, and control cabinets.
For stable heating performance, lamp selection should be considered together with:
Target material.
Required temperature.
Heating distance.
Line speed or cycle time.
Heating width and zone layout.
Reflector design.
Ventilation and cooling conditions.
Power control method.
Temperature feedback method.
Maintenance and replacement access.
YFR manufactures quartz infrared lamps for industrial heating and replacement applications. For single tube short wave IR lamps, production focuses on quartz tube quality, filament positioning, tube sealing, electrical performance, reflector coating, lead wire assembly, and packaging protection.
Main inspection points include:
Quartz tube visual inspection.
Filament and support structure inspection.
Tube sealing process control.
Reflector coating appearance check if applicable.
End cap and lead wire assembly inspection.
Electrical resistance and power matching.
Insulation and safety inspection according to order requirements.
Final visual inspection and export packaging.
A single tube IR lamp is an infrared heating lamp with one quartz tube. It is used as a radiant heating element in dryers, ovens, forming machines, coating lines, packaging machines, and other industrial equipment.
Yes. This page focuses on single tube short wave quartz halogen IR lamps. They provide fast response and high-intensity radiant heating for industrial heating applications.
Yes. YFR can customize lamp length, voltage, wattage, tube diameter, coating, end cap, lead wire, terminal, and packaging according to your equipment requirements.
Yes, if the dimensions, voltage, power, tube diameter, end structure, and terminals match. Please send the original lamp photos, markings, dimensions, and application details for confirmation.
Clear quartz, gold reflector coating, white ceramic reflector coating, half-coated reflector, and custom coating options can be supplied according to the heating direction and equipment structure.
Please provide total lamp length, heating length, voltage, power, tube diameter, coating, end cap type, lead wire length, terminal type, quantity, and application.
