Carbon Infrared Accelerates Acoustic-Part Molding

APPLICATION CONCEPT  |  AUTOMOTIVE INTERIORS

CUSTOM INDUSTRIAL INFRARED HEATING

PUBLIC CASE REFERENCE

Heat PE-EVA blanks in the tool
and remove a separate preheat step.

Zoned carbon infrared twin-tube emitters heat the PE-EVA sheet directly in the molding cell.

-20 sec REFERENCE CYCLE

Reference data subject to application testing and specification review.

Carbon Infrared Accelerates Acoustic-Part Molding industry application

The Process Challenge

Preheating acoustic insulation blanks can become a production bottleneck. Older foil heaters may carry maintenance cost and a separate warm-up stage.

The Infrared Approach

Zoned carbon infrared twin-tube emitters heat the PE-EVA sheet directly in the molding cell. Pyrometer feedback coordinates the heater and press cycle.

1

LOAD

Place the blank

2

HEAT

Raise material temp

3

MOLD

Shape in the tool

4

COOL

Stabilize the part

Application Features

  • In-tool or near-tool heating removes transfer time
  • Multiple zones follow the blank geometry
  • Fast response supports press synchronization
  • Pyrometer feedback controls material temperature
  • Modular emitters simplify service access

Typical Configuration

PUBLIC RESULT

Heat-up +16%; cycle reduced by 20 s

ENERGY REFERENCE

Preheat removed; reported saving 9 kW/h

REFERENCE SCALE

104 kW; 13 control zones

EMITTER

Carbon medium-wave twin-tube

CONTROL

Pyrometer and press PLC

CONFIRM

Material, thickness, mold and target temp

APPLICATION NOTE

Public case-study reference - not a YFR performance claim. Confirm equivalent results through YFR sample testing before publishing as a customer result.

Need a heating solution for this process?

Share your dimensions, target temperature and cycle time with YFR.
