APPLICATION CONCEPT | PAPER & PACKAGING
CUSTOM INDUSTRIAL INFRARED HEATING
Steam and hot-air dryers may remain warm through an entire shift. During stops they can keep heating the board and create waste or slow grade changes.
Carbon infrared modules are installed before each existing dryer section. The original equipment supplies ambient airflow while the IR modules provide responsive process heat.
COAT
Apply polymer layer
IR HEAT
Start drying
AIR DRY
Remove vapor
WIND
Finish the board
REFERENCE SCALE
Three 7 kW modules
REFERENCE LOAD
Typical operation at 30%-60%
EMITTER
Carbon medium-wave infrared
CONTROL
Line speed, load and stop interlock
AIR MANAGEMENT
Existing dryer used for ambient airflow
CONFIRM
Board, coating, speed and final moisture
APPLICATION NOTE
Public case-study configuration reference - not a YFR performance claim. Final ratings and results require YFR sample testing and engineering confirmation.
